Premium 4×1 4K USB-C & HDMI KVM Switch w/ USB 3.0 for 1 laptop & 3 desktops,up to 4K@60hz 4:4:4, keyboard hotkey or IR remote, auto PC wake-up & EDID emulation, 60W Charging for Laptop, 1080P@240/165hz & 2560×1440@144/120hz, Ideal for Home Office & Gaming, HDMI 2.0 & HDCP 2.2

4KSW41C-KVM

The AV ACCESS USB-C KVM Switch 4KSW41C-KVM is a premium 4-port KVM switch designed for professionals, content creators, and gamers who need to manage multiple computers with a single monitor, keyboard, and mouse. Featuring one full-function USB-C input and three HDMI inputs, this versatile KVM switch allows you to control up to four devices while keeping your workspace clean and organized.

Supporting 4K@60Hz (4:4:4) resolution, refresh rates up to 1080p@240Hz and 2560×1440@144Hz, plus 60W USB-C Power Delivery, the AV ACCESS USB-C KVM Switch 4KSW41C-KVM delivers outstanding visual performance and seamless productivity for both work and gaming.

Key Features

  • Control 4 computers or game consoles with one monitor, keyboard, and mouse
  • One full-featured USB-C input for video, data, audio, and 60W charging
  • Three additional HDMI inputs for desktop PCs and gaming consoles
  • Supports 4K@60Hz (4:4:4) with HDMI 2.0 and HDCP 2.2
  • High refresh rate support up to 1080p@240Hz and 1440p@144Hz
  • Built-in USB hub with 2× USB 3.0, 1× USB 2.0, and 1× USB 1.1
  • Switch devices using the front panel button, keyboard hotkey, or IR remote
  • Automatic PC Wake-Up for instant system access
  • EDID Emulation for stable and flicker-free display switching
  • Compatible with Windows, macOS, Linux, PS5, Xbox Series X/S, and Nintendo Switch
  • Plug-and-play installation with no software required
Technical
Input/Output Port 1 x USB C IN; 3 x HDMI IN; 1 x HDMI OUT; 3 x USB HOST (Type-B);1 x USB 1.1(Type-A); 1 x USB 2.0 (Type-A); 2 x USB 3.0 (Type-A); 1 x MIC IN (3.5mm TRS Connector); 1 x LINE OUT (3.5mm TRS Connector); 1 x HDMI OUT; 1 x DC 20V IN
Input/Output Signal Type HDMI Input/Output: HDMI 2.0b with 4K@60Hz 4:4:4, HDCP 2.2

USB C Input: USB 3.1, supports DP alt mode, and up to 4K@60Hz 4:2:0 8bit and 4K@30Hz 4:4:4 8bit

Input/Output Resolution Supported Up to 4K@60Hz 4:4:4 8bit (HDMI)

Note: USB C only supports up to 4K@60Hz 4:2:0 8bit or 4K@30Hz 4:4:4 8bit.

Audio Format HDMI: Fully supports audio formats in HDMI 2.0 specification, including PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, and DTS:X

MIC IN: Stereo

LINE OUT: Stereo

Maximum Data Rate HDMI: Up to 18Gbps

USB C: 5Gbps

Maximum Pixel Clock HDMI: 600MHz
Control Method Front panel buttons, IR remote, hotkey switching
General
Power Supply DC 24V 5A
Power Consumption (Max) 72.74W
Device Dimension

(W x H x D)

230mm x 26.2mm x 142.6mm/9.06” x 1.03” x 5.61”
Product Weight 0.86kg/1.90lbs
